Ứng dụng sản phẩm
- Shimadzu brand moisture drying scale is applied in many different industries and fields including:
Food production:
- Research and development of food products, beverages and food additives.
- Inspect food production processes and products.
- Measurement of raw materials (such as rice, malt, tea leaves and corn starch)
Chemical industry:
- Research and development of samples and product testing (solids, powders, pellets, lms and liquid samples)
- Static rate measurements for plastics, rubber, paints, pesticides and functional materials.
- Pharmaceutical and cosmetic industry:
- Pharmaceutical research and development (tablets, granules, capsules and ointments)
- Research and development of cosmetics (such as hair products, facial creams and soaps)
- Check the production of pharmaceuticals and cosmetics according to the process.
Metallurgical industry:
- Strength ratio measurements of raw materials (such as iron ore)
- Strength ratio measurements of metals (such as metal powders)
- Strength ratio measurements of wood, paper, and lime.
Environment and water treatment industry:
- Static ratio measurements and sludge testing.
- Measure the strength ratio and test the soil.
- Static rate measurements and waste checks.
Automotive and electric manufacturing industry:
- Strength ratio measurements of plastic beads and plastic parts.
- Toner powder static ratio measurements.
How to use Shimadzu moisture drying scale
- Step 1: Take about 1g of pure coffee sample into the drying pan, note that the coffee should be evenly distributed on the pan.
- Step 2: Set the drying time and temperature, the appropriate temperature is about 140 degrees Celsius, the time is 10 minutes.
- Step 3: Repeat the above 2 steps 3 times and the sample weight increases a little, then take the average value of the moisture ratio after drying and compare with the test sample.
- Accessories included with the machine:
- Fuse.
- Sample pan.
- Aluminum plate.
- Sample pan handling.
Optional accessories:
- Printer EP-80 / printer EP-90.
- Protective cover when used for the screen (5 pieces).
- Aluminum plate
- Fiberglass sheet.
- Temperature calibration kit.
- Sample pan (SUS)
- RS-232C . Cable
- USB connection cable
Thông số kỹ thuật
- Max capacity 60g
- Minimum capacity 0.02g
- Minimum readability 0.001g 0.01 / 0.1%(optional)
- Repeatability 0.15% (2g) 0.05% (5g) 0.02% (10g)
- Moisture drying technology Vertical halogen lamp
- Power 400W
- Temperature range 50-200°C
- Backlit LCD display screen
- Pan size Diameter 95mm
- Dimensions 202 × 336 × 157
- Weight 4kg
- Temperature and humidity range 5 to 40°C
- humidity 85% RH or less
- Timer mode 1-120 minutes or continuous
- measuring condition data memory 10
- data memory 100
- Measurement Mode Standard , Quick drying , Slow drying
