Martindale Abrasion Tester with 9 stations

Ứng dụng sản phẩm
Thông số kỹ thuật
Tiêu chuẩn
Video

Ứng dụng sản phẩm

The machine is used to determine the abrasion and knotting resistance of fabrics using the Martindale method
The machine is suitable for testing woven and knitted fabrics, fabrics, and non-woven fabrics
Martindale's fabric is available with 9
The Martindale Abrasion Test was developed primarily to evaluate the abrasion resistance of wool and textile fabrics and is not suitable for fabrics with surface coating.
The Martindale is equipped with an advanced 7” Touchscreen controller that provides the operator with an easy-to-read display and simple controls to operate the machine. The emergency stop switch is located for ease of use if the operator needs to stop the machine quickly.
Martindale is capable of operating within 24 hours. The test time is calculated from when the machine started and the current time. For the calculation to be accurate, it is necessary to set the correct time
Martindale can be configured to perform tests requiring different wear patterns. The equipment delivered is set up for standard abrasion testin

Thông số kỹ thuật

The main parts of the equipment are made of stainless steel, aluminum, and technical plastics, to avoid oxidation, even in wet tests.
The quality of the materials and their finish ensures uniform, smooth and no vibration movement of the holder guide plate.

Tiêu chuẩn

ISO 12947-1;
EN ISO 5470-2;
EN ISO 20344:6.12;
EN ISO 17704;
EN ISO 12945-2.

Video

Please contact us for advice and support
⇒ Mr. Ba: 0948.27.99.88

⇒ Or leave a message and we will call you directly. Thank you very much!
