Rigidity Tester for soles

Model: H012
Producer: HiLAB-Portugal
Giá: Contact
Assess the longitudinal rigidity of complete footwear to determine if “Bennewart” flexing test should be done, according EN ISO 20344:8.5 and ISO 17707.
Buy now Nationwide Delivery
0948279988 Contact phone number

Ứng dụng sản phẩm

  • A smooth metal hinge plate, fixed to a rigid base
- Clamping device to fix the front part of the footwear under test to the rigid sole
- Sensor has measuring force range from 0 to 50 N, accuracy ± 1%;
  • The bending of metal sheets is done by hand. Force and angle are both recorded as a digital device records both force and angle values ​​respectively.
  • To avoid oxidation, both panels are made of stainless steel.

Thông số kỹ thuật

Tiêu chuẩn

  • EN ISO 20344:8.5 and ISO 17707

Video

Please contact us for advice and support
⇒  Mr. Ba: 0948.27.99.88

⇒  Or leave a message and we will call you directly. Thank you very much!
